TECHNICAL DATA
Pneumatic section of gearbox CF65/75/85 series
3-2
GEAR LEVER SELECTOR VALVE
Range-change gear
Connection point
Colour
1 Supply Black
3 Bleed Red
21 Range-change gear
command (A)
White
V300488
21
1
B
A
3
PNEUMATIC SYMBOL
III
V300267
13
21
Range
0
ᓻ 200337
