3
CF65/75/85 series Draining and filling
AUTOMATIC GEARBOXES
5-1
5. DRAINING AND FILLING
5.1 DRAINING AND FILLING, GEARBOX
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
Draining the gearbox
1. Bring the gearbox to operating temperature
(approx. 71_C-93_C) before the oil is
drained, so that the oil can be drained more
quickly and more completely.
2. Place the vehicle on a level surface.
3. Remove the drain plug (1) from the gearbox
oil sump.
4. Remove the oil filters (2). See “Removal
and installation”.
Filling the gearbox
1. Clean the drain plug (1) and, fitted with a
new sealing ring, tighten it to the specified
torque. See “Technical data”.
2. Install the oil filters (2). See “Removal and
installation”.
3. Fill the gearbox through the dipstick holder
with the specified oil quantity. See
“Technical data”.
V300371
2
1
W 3 03 098
9
ᓻ 200337
