DAF CF75 Series - Page 128

3
GEARBOX - PNEUMATIC SECTION
General CF65/75/85 series
1-6
2. Electropneumatic downshift valve (2)
At the side of the gearbox.
3. Filter/governor (3)
At the side of the gearbox.
4. Range-change gear engaging
cylinder (4)
At the side of the gearbox.
V300452
2
3
4
5. Reversing switch (6)
At the side of the gearbox.
6. Neutral switch (7)
At the side of the gearbox.
7. Speed sensor (8)
At the rear of the gearbox.
V300453
5
8
6
7
8. VIC electronic unit
In the central box on the co-driver’s side (1).
V300418
1
4
ᓻ 200337
