3
CF65/75/85 series Inspection and adjustment
GEARBOX - PNEUMATIC SECTION
3-1
3. INSPECTION AND ADJUSTMENT
3.1 SIMULATION OF THE SPEED SIGNAL
The speed signal can be simulated using DELSI
(DAF No. 0694941). DELSI must be connected
to the speed sensor connector.
To connect DELSI to the speed sensor
connector, an adapter cable needs to be made.
The adapter cable must consist of the following
wiring:
Pin 1: speed sensor, power supply
Pin 2: speed sensor, earth
Pin 3: speed sensor,
real-time speed/distance signal
Pin 4: not in use
When the speed sensor connector is
disconnected, a fault is stored in the tachograph.
This error can be deleted using DAVIE XD.
V300425
24
31
K100873
4
ᓻ 200337
