DAF CF75 Series - Page 170

3
GEARBOX - PNEUMATIC SECTION
Inspection and adjustment CF65/75/85 series
3-6
3. Using an Allen key (2) lowered into the
opening of the stop, the adjusting screw (3)
can be turned to correct the travel (C). See
“Technical data”.
4. Fit the stop.
V300316
3
5. Adjust the travel (D) by means of the
adjusting screw (1). See “Technical data”.
6. Check the operation of the GV valve.
V300315
C
D
B
1
A
4
ᓻ 200337
