3
CF65/75/85 series General
ZF 6S-850 GEARBOX
1-1
1. GENERAL
Gearbox type
Each gearbox has a type plate attached to it,
indicating the type of gearbox. This data can
also be found on the identity card for the vehicle
concerned.
ZF gearbox type-plate
1. Type of gearbox
2. Serial no. (ZF)
3. Parts list (ZF)
4. Specification no.
5. Pulse generator ratio
6. Gearbox ratio
7. Engine speed using PTO
8. PTO speed
9. Gearbox oil capacity
10. Oil specification
V300049
1
2
4
5
3
8
6
7
10
9
1.1 SYSTEM DESCRIPTION, ZF 6S-850 GEARBOX
The gearbox consists of six synchronised
forward gears, and one non-synchronised
reverse gear.
V300466
5
ᓻ 0111
