3
CF65/75/85 series Contents
ZF 8/9/16S-109 GEARBOX
1
CONTENTS
Page Date
1. GENERAL 1-1 0111............................................................ ......
1.1 System description, 16S gearboxes 1-2 0111................................. ......
2. COMPONENT DESCRIPTION 2-1 0111........................................... ......
2.1 Synchroniser 2-1 0111..................................................... ......
3. INSPECTION AND ADJUSTMENT 3-1 0111....................................... ......
3.1 Inspection, gearbox oil level 3-1 0111........................................ ......
3.2 Inspection and adjustment, input shaft bearing axial clearance 3-2 0111.......... ......
3.3 Inspection and adjustment, gearbox output shaft bearing axial clearance 3-4 0111. ......
3.4 Inspection and adjustment, selector shaft housing on gearbox 3-5 0111........... ......
4. REMOVAL AND INSTALLATION, GEARBOX 4-1 0111.............................. ......
4.1 Removal and installation , entire gearbox 4-1 0111............................. ......
4.2 Removal and installation, drive flange 4-3 0111................................ ......
4.3 Removal and installation, output shaft oil seal 4-5 0111......................... ......
4.4 Removal and installation, gearbox front cover sealing ring 4-6 0111.............. ......
4.5 Removal and installation, selector shaft oil seal 4-7 0111....................... ......
5. DRAINING AND FILLING 5-1 0111............................................... ......
5.1 Draining and filling, gearbox 5-1 0111........................................ ......
5.2 Gearbox ZF 8/9/16S-109 with integrated retarder 5-2 0111...................... ......
6
ᓻ 0111
