DAF CF75 Series - Page 202

3
ZF 8/9/16S-109 GEARBOX
General CF65/75/85 series
1-4
8/9S 109
The four gears in the main gearbox are doubled
when the auxiliary gearbox is used, giving
4 x 2 = 8 or, with the crawler gear as well,
9 forward gears.
The diagram shows the power distribution
across the individual gear pairs for each gear.
Direct input shaft version of the ZF 16S-109
D = splitter “Direct”
S = splitter “Fast”
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
D
S
1
2
3
4
5
6
7
8
R
W 3 03 055
ᓻ 0111
6
