CF65/75/85 series Contents
ZF 8/16S-151/181 AND 16S-221 GEARBOXES
1
CONTENTS
Page Date
1. GENERAL 1-1 200337............................................................ ....
1.1 System description 1-2 200337................................................ ....
2. DESCRIPTION OF COMPONENTS 2-1 200337....................................... ....
2.1 Synchroniser 2-1 200337..................................................... ....
3. INSPECTION AND ADJUSTMENT 3-1 200337....................................... ....
3.1 Inspection of gearbox oil level 3-1 200337...................................... ....
3.2 Inspection and adjustment, input shaft bearing axial play 3-3 200337............... ....
3.3 Inspection and adjustment, gearbox output shaft bearing axial play 3-4 200337...... ....
3.4 Inspection and adjustment, selector shaft housing on gearbox 3-5 200337........... ....
4. REMOVAL AND INSTALLATION OF GEARBOX 4-1 200337........................... ....
4.1 Removal and installation, gearbox assembly with or without
integrated retarder 4-1 200337................................................ ....
4.2 Removal and installation, prop shaft flange 4-4 200337........................... ....
4.3 Removal and installation, output shaft oil seal 4-6 200337......................... ....
4.4 Removal and installation, gearbox front cover oil seal 4-7 200337.................. ....
4.5 Removal and installation, selector shaft oil seal 4-8 200337....................... ....
5. DRAINING AND FILLING 5-1 200337............................................... ....
5.1 Draining and filling, gearbox 5-1 200337........................................ ....
7
ᓻ 200337
