CF65/75/85 series Inspection and adjustment
ZF 8/16S-151/181 AND 16S-221 GEARBOXES
3-1
3. INSPECTION AND ADJUSTMENT
3.1 INSPECTION OF GEARBOX OIL LEVEL
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
ZF 8S/16S-151/181 and 16S -221 gearboxes
1. Position the vehicle on a level surface.
2. Wait for some minutes to allow the oil to
flow back.
Note:
The oil level must reach the rim of the level
check/filler opening (A).
3. Remove the level check plug (A) and check
the oil level.
4. After checking the oil level, tighten the level
check plug to the specified torque. See
“Technical data”.
M3023
D
A
B
C
ᓻ 200337
7
