3
CF65/75/85 series Disassembly and assembly
PROP SHAFTS
4-5
4.2 DISASSEMBLY AND ASSEMBLY, CENTRE BEARING
Disassembling the centre bearing
1. Hang the auxiliary shaft carefully on the
chassis.
2. Remove the bolts that attach the flange to
the prop shaft and the auxiliary shaft. Also
secure the prop shaft carefully to the
chassis.
3. Attach the special tool (DAF no. 0484977)
to apply counter-pressure against the
flange, and remove the central nut and the
washer.
4. Mark the flange and shaft end with a centre
point to ensure that the forks can all be
fitted later in one line.
5. Remove the attachment bolts from the
centre bearing and the chassis bracket.
W 3 06 029
11
ᓻ 0111
