DAF CF75 Series - Page 423

3
CF65/75/85 series General
PTO
2-13
2.9 OVERVIEW DRAWING, NL/1 AND NH/1 PTO, C VERSION
V300873
2
4
1
5
6
7
8
9
10
3
1
11
1. Studs
2. Gasket
3. PTO housing
4. Gasket
5. Synchroniser sleeve
6. Spring
7. Piston
8. Centring ring
9. PTO-housing cover
10. Lock washer and nut
11. PTO control switch (depending on version,
this may be of the reed switch type)
13
ᓻ 200337
