DAF CF75 Series - Page 425

3
CF65/75/85 series General
PTO
2-15
2.11 OVERVIEW DRAWING, NL/4 AND NH/4 PTO, C VERSION
V300875
4
2
1
1
3
6
7
8
9
10
5
9
11
1. Studs
2. Gasket
3. NH/4 needle bearing width 16 mm
NL/4 needle bearing width 12 mm
4. PTO housing
5. Lock washer and nut
6. Gear
7. Gasket
8. Transport cover
9. Lock washer and nut
10. Lock washer and nut
11. PTO control switch (depending on version,
this may be of the reed switch type)
13
ᓻ 200337
