3
CF65/75/85 series General
PTO
2-19
2.17 OVERVIEW DRAWING, Z81 PTO, B VERSION
1
2
2
4
5
3
V300629
7
8
2
10
11
12
13
9
6
1. Stud
2. Gasket
3. Adapter plate, lubrication
4. PTO housing
5. Air connection
6. Synchroniser sleeve
7. Sleeve spring
8. Piston
9. Spacer ring
10. PTO housing cover
11. Lock washer and nut
12. Shaft seal
13. Drive flange
13
ᓻ 200337
