DAF CF75 Series - Page 440

3
PTO
Inspection and adjustment CF65/75/85 series
3-6
3.4 INSPECTION AND ADJUSTMENT, AXIAL PLAY OF NL/1 PTO ON
N221/10 PTO
1. Remove the cover (1) and shim (2) of the
N221/10 PTO.
V300639
1
2
2. Use a depth gauge to measure the depth
down to the outer bearing race, distance A.
A
V300230
3. Install a new gasket (4) in the intermediate
housing (3).
V300640
3
4
5
13
ᓻ 200337
