3
PTO
Removal and installation CF65/75/85 series
4-16
4.14 REMOVAL AND INSTALLATION, Z81 PTO, C VERSION
Removing Z81 PTO, C version
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the lubricating oil pipe, electrical
connector and air pipe from the PTO.
3. Remove the drive flange, which is mounted
against the PTO flange.
4. Remove the attachment nuts connecting the
PTO to the gearbox and remove the PTO
including adapter plate and gaskets.
5. If necessary, remove the intermediate shaft.
Installing Z81 PTO, C version
1. If necessary, install the intermediate shaft.
2. Fit the gaskets and adapter plate over the
studs.
3. Install the PTO on the gearbox.
4. Fit the attachment nuts onto the studs of the
gearbox and the PTO.
5. Fit the lubricating oil pipe, the electrical
connector and air pipe to the PTO.
6. Install the drive flange against the
PTO flange.
7. Check the oil level in the gearbox.
13
ᓻ 200337
