3
PTO
Removal and installation CF65/75/85 series
4-18
4.16 REMOVAL AND INSTALLATION, 2266 PTO, C VERSION
Removing 2266 PTO, C version
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the lubricating oil pipe, electrical
connector and air pipe from the PTO.
3. Remove the drive flange, which is mounted
against the PTO flange.
4. Remove the attachment bolts connecting
the PTO to the gearbox and remove the
PTO including gasket.
5. If necessary, remove the intermediate shaft.
Installing 2266 PTO, C version
1. If necessary, install the intermediate shaft.
2. Fit the gasket over the attachment bolts of
the PTO.
3. Install the PTO on the gearbox.
4. Fit the lubricating oil pipe, the electrical
connector and air pipe to the PTO.
5. Install the drive flange against the
PTO flange.
6. Check the oil level in the gearbox.
13
ᓻ 200337
