GEARBOX - PNEUMATIC SECTION
Description of components CF65/75/85 series
2-14
2.8 FILTER/GOVERNOR, EATON FS/6309A
Filter/governor (1) on gearbox
2 3 415
V300558
Overview drawing, filter/governor,
Eaton FS/6309A
1. Filter/governor housing
2. Filter element
3. Sealing ring
4. O-ring
5. Cover
6. Plug
7. Output
8. Selector valve output plug
9. Attachment bolt
10. Supply pressure input
6
5
4
3
2
1
10
9
8
V300430
7
4
