CF65/75/85 series Clutch
TECHNICAL DATA
9-5
9.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
Main cylinder
Pressure pin attachment nut 55 Nm
Bleeder 8 Nm
Steel pipe coupling 40 Nm
Clutch release assembly
ZF gearboxes
Attachment bolts, clutch release assembly to
flywheel
54 Nm
Attachment bolt, automatically adjusting clutch
release assembly stop plate
39 Nm
(1)
(1) Loctite 648
ZF 6S-850
Attachment bolts, clutch release assembly to
flywheel
54 Nm
Attachment bolts, clutch lever to gearbox 27 Nm
8/9/16S-109
M16 round bolt, clutch lever to clutch housing 90 Nm
8/16S-151/181/221
M8 attachment bolts, clutch lever to gearbox 30 Nm
EATON FS/6309A gearbox
Attachment bolts, clutch release assembly to
flywheel
54 Nm
Attachment bolts, clutch lever to gearbox 27 Nm
ᓻ 200337
