CF65/75/85 series Disassembly and assembly
PTO
5-3
5.2 DISASSEMBLY AND ASSEMBLY, DAF ENGINE PTO HOUSING
Disassembly, DAF engine PTO housing
1. If fitted, remove the drive flange.
2. At the rear of the PTO housing, remove the
sealing plate attachment bolts of the drive
shaft with the gasket.
3. Place the engine PTO mounting ring (1)
(special tool, DAF No. 1329342) on the
drive shaft and clamp it firmly in a vice.
4. Remove the lock nut from the drive shaft.
5. If fitted, remove the pneumatic valve.
6. If fitted, remove the shift control.
7. Remove the drive housing attachment nuts
and the drive-side cover with oil seal, if
fitted.
8. If necessary, remove the short drive shaft
with bearing and selector ring from the
PTO housing.
9. Remove the prop shaft from the
PTO housing with the adjusting rings and
drive sprocket.
10. If necessary, remove the needle bearing for
the short drive shaft from the prop shaft.
11. If necessary, remove the two outer bearing
races from the PTO housing.
12. If necessary, remove the bearing from the
prop shaft.
V300642
1
13
