TECHNICAL DATA
Mechanical gearbox control CF65/75/85 series
1-2
ADJUSTING THE LINKAGE MECHANISM
Vehicle series CF65/75/85 LHD/RHD with
ZF 6S-850, 8/9/16S-109, 8/16S-151/181/221
and Eaton FS/6309A gearboxes.
Angle A: 90_
Note:
After the gear lever has been manually
positioned at an angle of 90_, the linkage
mechanism should be fitted together with the
selector shaft lever.
V300383
A
Vehicle series CF65 / RHD with gearbox type
ZF 6S-850
If the selector shaft lever has two attachment
holes, the attachment hole (A) in the selector
shaft lever should be used to attach the shaft
lever properly to the control rod.
A
V300833
Bonding the gear lever into the ball
De-greaser DAF No. 1322827
Glue DAF No. 1340646
Bonding the ball joint to the control rod
De-greaser DAF No. 1322827
Glue DAF No. 1340646
0
ᓻ 200337
