CF65/75/85 series Pneumatically assisted gearbox control (Servoshift)
TECHNICAL DATA
2-1
2. PNEUMATICALLY ASSISTED GEARBOX CONTROL
(SERVOSHIFT)
2.1 GENERAL
Servoshift unit
Service pressure max. 10 bar
2.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
Air pipe banjo bolt (1) 38 Nm
Attachment bolts:
Servoshift unit (2) 23 Nm
V300328
2
1
ᓻ 200337
