SECTION 1
GENERAL
TBM
700 PILOT’S OPERA TING HANDBOOK
Page 1.3.1
Rev. 12
1.3 -- DESCRIPTIVE DATA
ENGINE
Number of engines : 1
Engine manufacturer : PRATT & WHITNEY CANADA
Engine model number : PT6A -- 64
Engine type : Free turbine, reverse flow and 2 turbine sections
Compressor type : 4 axial stages
1 centrifugal stage
Combustion chamber type : Annular
Turbine type : 1 gas generator turbine stage
2 power turbines stages
Horsepower rating and propeller speed : 700 SHP at 2000 RPM
PROPELLER
Number of propellers : 1
Propeller manufacturer : HARTZELL
Propeller model number : HC--E4N--3 / E9083S (K)
Number of blades : 4
Propeller diameter :
Minimum : 90 inches (2.286 m)
Maximum : 91 inches (2.311 m)
Propeller type : Adjustable constant speed, with feathering and hydraulic
control reverse
Propeller blade setting at 30 inches station
Low pitch : 21°
Feathering : 86°
Maximum reverse : - 11°
Propeller governor : 8210.007 WOODWARD
PIM - DO NOT USE FOR FLIGHT OPERATIONS
