TBM
PILOT’S OPERATING HANDBOOK 700
SECTION 1
GENERAL
Page 1.3.4
Rev. 7
MAXIMUM CERTIFICATED WEIGHTS
Ramp : 6614 lbs (3000 kg)
Takeoff : 6579 lbs (2984 kg)
Landing : 6250 lbs (2835 kg)
Baggage weight (refer to Section 6 for cargo loading instructions) :
In FWD compartment (non pressurized) : 110 lbs (50 kg)
In aft compartment (pressurized) : 220 lbs (100 kg)
STANDARD AIRPLANE WEIGHTS
TBM700A
:
Standard empty weight : 4050 lbs (1837 kg)
Maximum useful load : 2564 lbs (1163 kg)
TBM700B
:
Standard empty weight : 4167 lbs (1890 kg)
With ”pilot” door : 4211 lbs (1910 kg)
Maximum useful load : 2447 lbs (1110 kg)
With ”pilot” door : 2403 lbs (1090 kg)
CABIN AND ENTRY DIMENSIONS
Maximum cabin width : 3’ 11.64” (1.21 m)
Maximum cabin length : 13’ 3.45” (4.05 m)
Maximum cabin height : 4’ (1.22 m)
TBM700A
:
Number of cabin entries : 1
Entry width : 2’ 1.59” (0.65 m)
Entry height : 3’ 10.85” (1.19 m)
TBM700B
:
Number of cabin entries : 1 (standard) + 1 ”pilot” door (if installed)
Entry width (standard) : 3’ 6.52” (1.08 m)
Entry height (standard) : 3’ 10.85” (1.19 m)
”Pilot” entry mean width : 2’ 3.6” (0.70 m)
”Pilot” entry mean height : 3’ 2.16” (0.97 m)
BAGGAGE SPACE ENTRY DIMENSIONS (NON PRESSURIZED)
Access by L.H. side door
Entry width : 1’ 2.57” (0.37 m)
Entry height : 1’ 8.08” (0.51 m)
SPECIFIC LOADINGS
Wing loading : 34 lbs / sq.ft (165.8 kg / m
2)
Power loading : 9.4 lbs / SHP (4.26 kg / SHP)
