Technical data – subject to technical modifications!
Model 70104 70103
70204
Max. width
Laminating fi lms
A4
230 mm/9.0“
A3
325 mm/12.8“
A4
230 mm/9.0“
Max. laminating thickness 0.5 mm
Max. thickness of laminating film 2x80 micron / 2x125 micron
Rated voltage 220–240 V; 50–60 Hz
Effective Current 1.3 A 1.7 A 2.5 A
Max. Current/Heating time 1.3 A 1.7 A 6.1 A
Effective Power Consumption 265 W 365 W 575 W
Max. Power Consumption/Heating Time 265 W 365 W 1400 W
Heating time 3–5 minutes 3–5 minutes 30 seconds
Lamination speed 250 mm/min 250 mm/min 500 mm/min
Automatic shut-off function when not
in use
No No After 30 minutes
Cold lamination Yes Yes No
Weight 1.25 kg 1.7 kg 1.5 kg
Dimensions
Width: 360 mm
Depth: 150 mm
Height: 78 mm
Width: 454 mm
Depth: 150 mm
Height: 78 mm
Width: 360 mm
Depth: 150 mm
Height: 78 mm
Model 70203 70304
70303
Max. width
Laminating fi lms
A3
325 mm/12.8“
A4
230 mm/9.0”
A3
325 mm/12.8“
Max. laminating thickness 0.5 mm
Max. thickness of laminating film 2x80 micron / 2x125 micron
Rated voltage 220–240 V; 50–60 Hz
Effective Current 2.5 A 2.5 A 2.5 A
Max. Current/Heating time 6.1 A 6.1 A 6.1 A
Effective Power Consumption 575 W 575 W 575 W
Max. Power Consumption/Heating Time 1400 W 1400 W 1400 W
Heating time 40 seconds 30 seconds 40 seconds
Lamination speed 500 mm/min 500 mm/min 500 mm/min
Automatic shut-off function when not
in use
After 30 minutes After 30 minutes After 30 minutes
Cold lamination No No No
Weight 2.0 kg 2.0 kg 2.6 kg
Dimensions
Width: 454 mm
Depth: 150 mm
Height: 78 mm
Width: 360 mm
Depth: 150 mm
Height: 78 mm
Width: 454 mm
Depth: 150 mm
Height: 78 mm
Dispose of the laminating device properly in an environmentally friendly way at an author-
ised collection point. Do not dispose of any parts of the laminating device or packaging in
domestic waste.
