User’s Manual
272
3G/4G
The 3G/4G page consists of three areas:
Area 1: Displays the signal strength.
Area 2: Displays the module configurations.
Area 3: Displays the connection state.
The information of Area 2 will display after the 3G/4G module is connected; while the
information of Area 1 and Area 3 will display only after the 3G/4G function is enabled.
The Device starts identifying the wireless module and displays the recognized information for
the parameters in Area 2.
Table 5-50 Recognized information
NIC Name Displays the name of Ethernet card.
Network Type Displays the network type. Different type represents different supplier.
APN Displays the default APN number.
Dial-up No. Displays the default dial No.
Authentication
Type
Authentication mode. You can select
,
, or
.
Username,
Password
Enter the username and password for authentication.
Select the Enable checkbox.
Click Dial to start connecting.
After the connection is established, the result is displayed in the Wireless Network area.
