User Manual
Code: DH-IPC-HFW1320SP-W-
IP CAMERA DH-IPC-HFW1320SP-W- Wi-Fi, 3.0 Mpx 2.8 mm DAHUA
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-06-19 DH-IPC-HFW1320SP-W- 2/6
IP camera with efficient H.264 image compression algorithm for
clear and smooth video streaming at maximal resolution of 3 MPx.
The cameras of the Dahua Consumer series have been designed with
special care to simplify the configuration and operation. In
combination with the user friendly imou platform, the Dahua
Consumer series devices allow anyone to create a simple and
effective surveillance system.
The used Wi-Fi module allows to remote communication with camera
for max. distance up to 50 m.
The range of IR illumination according to the manufacturer data,
depends on outer conditions (visibility - air transparency,
environment, wall colors ie. scene reflectance).
Attention! The Dahua Consumer cameras are dedicated to
management only via the imou application (previous name
Lechange). The IMOU series devices do not have a WEB interface.
The Consumer series records the data only after motion detection
(no continuous recording) - recording approx. 1 - 1.5 minutes
depending on the duration of the movement in front of the camera.
In order to obtain optimal performance of DAHUA Consumer series
cameras, it is recommended to use DAHUA Micro SD memory cards.
Standard: TCP/IP
Sensor: 1/3 " Progressive Scan CMOS
Matrix size: 3.0 Mpx
Scanning system: Progressive
Resolution: 2304 x 1296 - 3.0 Mpx
Lens: 2.8 mm
View angle: 100 °
Range of IR illumination: 30 m
S/N ratio: > 50 dB
RS-485 interface:
Image compression method: / H.264
Alarm inputs / outputs:
Audio:
Bitrate: 448 kbps ... 10240 kbps - H.264
Main stream frame rate: 20 fps @ 3.0 Mpx
Network interface: 10/100 Base-T (RJ-45), Wi-Fi IEEE 802.11 b/g/n
