As regards general tools (those tools which are normally provided in a service shop), jacks and other
standard equipment, they are omitted in this workshop manual.
As for those Special Service
Toois (SSTs) which are necessary for the service operations, they are posted
collective!y in the tables under SECTION 11 APPENDIX. Hence, please prepare them prior to the service
operation.
In respect to instruments, lubricants and so forth, be sure to use those designated by Daihatsu.
WM-C1002
[Composition]
1.
The component diagram is provided in the beginning of each section. Refer to this component d.iagram
whenever you want to assure the shape or the part name of each part during the installation operation
or the removal operation.
2. In principle, each section is arranged in the foilowing crder. However, it should be noted
that the
composition for the in-vehicle operation differs from this order.
However, instances where the removal or the installation is comparatively easy or no SST or the like is
required, the arrangement is made as follows:
Removal Procedure
3.
With regard to the tightening torque specifications, they are indicated in the Engine Components and
Tightening Torque under SECTION 3-10. In addition, they are shown in the tables under SECTION 11
SERVICE SPECIFICATIONS.
However, as for those items where no specific tightening torque is mentioned, perform the operation
referring to the Tightening Torque for Main Components under SECTION
00.
WM-01003
I
Inspection -~lnstallation Procedure
[Numerals]
As regards those numerals which are posted under "Inspection" and under sections other than SECTIOr'
11 SERVICE SPECIFICATIONS, those numerals from the specified values to the allowable limits a*
posted.As
for those numerals which are posted under SECTION 11 SERVICE SPECIFICATIONS, those
numerals concerning the specified values and allowable limits are indicated separately.
WM-01004
[NOTE]
1.
"NOTES" posted in the main text clearly show those items which need particular attention or prohibited
items which must be avoided during the service operation.
2. Prior to the operation, make certain to take any necessary precautionary measures so as to prevent
personal injury during the
removal/installation of parts.
'NM-01005
