Si121174 Removal of Outer Panels
Removal Procedure 5
9
Remove the 4 screws
of the discharge grille.
10
11
Remove the 2 screws
of the stop valve cover.
Slide the stop valve
cover downward and
remove it.

When reassembling, make
sure to fit the 5 hooks.
Step
Procedure Points
Discharge grille
(R12902)
(R11206)
Stop valve cover
(R5506)
(R5508)
