English 9
Installation
Installation of wire harness to Wireless LAN adapter
1
Remove the adapter case (upper).
Press a regular screwdriver into the dent between the upper and lower
cases to remove. (Be careful not to damage the case.)
Regular screwdriver
Adapter
case (upper)
Adapter
case (lower)
Wireless LAN
connecting adapter
printed circuit board
Installation
Work
