Daikin FHQ71BVV1B Technical Data

2
• Split Sky Air • Indoor Units
3
• Indoor Units • R-410A • FHQ-BVV1B
2 Specifications
2-1 FOR INDOOR UNITS ONLY FHQ35BVV1B FHQ50BVV1B FHQ60BVV1B FHQ71BVV1B FHQ100BVV1B FHQ125BVV1B
Nominal Input Cooling kW 0.111 0.111 0.115 0.117 0.135 0.144
2-2 TECHNICAL SPECIFICATIONS FHQ35BVV1B FHQ50BVV1B FHQ60BVV1B FHQ71BVV1B FHQ100BVV1B FHQ125BVV1B
Casing Colour White
Dimensions Packing Height mm 279 279 279 279 275 275
Width mm 1046 1046 1246 1246 1486 1676
Depth mm 818 818 818 818 818 818
Unit Height mm 195 195 195 195 195 195
Width mm 960 960 1160 1160 1400 1590
Depth mm 680 680 680 680 680 680
Weight Unit kg 24.0 25.0 27.0 27.0 32.0 35.0
Packed Unit kg 31.0 32.0 35.0 35.0 41.0 45.0
Heat
Exchanger
Dimensions Length mm 722 722 922 922 1162 1352
Nr of Rows 232333
Fin Pitch mm 1.75 1.75 1.75 1.75 1.75 1.75
Nr of Passes66661111
Face
Area
m² 0.182 0.182 0.233 0.233 0.293 0.341
Nr of Stages 12 12 12 12 12 12
Empty Tubeplate
Hole
2
Tube type N-Hix
Fin Type ML fin (Multi louver)
Fan Type Sirocco fan
Quantity 334434
Air Flow Rate Cooling High m³/min 13.0 13.0 17.0 17.0 24.0 30.0
Low m³/min 10.0 10.0 13.0 14.0 20.0 25.0
Heating High m³/min 13.0 13.0 16.0 17.0 24.0 30.0
Low m³/min 10.0 10.0 13.0 14.0 20.0 25.0
FanMotorQuantity 111111
Model 3D12K1AA1 3D12K1AA1 4D12K1AA1 4D12K1AA1 3D12K2AA1 4D12K2AA1
Number of steps222222
Output
(high)
W62626262130130
Cooling Sound Power High dBA 53.0 54.0 55.0 55.0 58.0 60.0
Low dBA 48.0 49.0 49.0 51.0 53.0 55.0
Sound
Pressure
High dBA 37.0 38.0 39.0 39.0 42.0 44.0
Low dBA 32.0 33.0 33.0 35.0 37.0 39.0
Heating Sound Power High dBA 53.0 54.0 55.0 55.0 58.0 60.0
Low dBA 48.0 49.0 49.0 51.0 53.0 55.0
Sound
Pressure
High dBA 37.0 38.0 39.0 39.0 42.0 44.0
Low dBA 32.0 33.0 33.0 35.0 37.0 39.0
Refrigerant Type R-410A
Piping
connections
Liquid (OD) Type Flare connection
Diameter
(OD)
mm6.46.46.49.59.59.5
Gas Type Flare connection
Diameter
(OD)
mm 9.5 12.7 12.7 15.9 15.9 15.9
Drain Diameter
(OD)
mm VP20 (I.D. 20/O.D. 26)
Heat Insulation Foamed polystyrene/polyethylene
Safety Devices Fuse Fuse Fuse
Fan motor thermal protector
