DAMA-SM-21-001 Specification Data
Specifications 19
1) ALL UNITS ARE BEING TESTED ACCORDING TO AHRI 210/240 STANDARD.
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL
INDOOR UNIT FTX12A
OUTDOOR UNIT
RX12A
Cooling Heating
Rated Capacity (Min. ~ Max.)
kW 3.20 (1.30 - 3.90) 3.96 (1.30 - 4.80)
Btu/h 10900 (4400 - 13300) 13500 (4400 - 16400)
Moisture Removal gal/h 0.19
Rated Running Current A 3.99 4.70
Rated Power Consumption W 872 1038
EER Btu/h/W 12.5 N/A
SEER 19.0 N/A
COP W/W N/A 3.80
HSPF N/A 10.0
Power Factor (Rated) N/A
Piping
Connections
Liquid inch (mm) 1/4” (6.35)
Gas inch (mm) 3/8” (9.52)
Refrigerant
Type R410A
Charge lbs (kg) 2.09 (0.95)
Max. Interunit Piping Length ft (m) 65-5/8 (20)
Max. Interunit Height Difference ft (m) 49-1/4 (15)
Chargeless ft (m) 32-13/16 (10)
Amount of Additional Charge of Refrigerant oz/ft (g/m) 0.21 (20)
INDOOR UNIT FTX12A
Front Panel Colour WHITE
Airflow Rate
Turbo CFM 473
High CFM 436 412
Medium CFM 316
Low CFM 247
Quiet CFM 210
Sound Pressure Level (H/M/L/Q) dBA 45/37/31/26 45/37/30/26
Fan
Type CROSS FLOW
Drive DIRECT
Speed 3 STEPS, QUIET, AUTO, TURBO
Fan Motor
Type DIRECT CURRENT
Motor Output W 38
Running Current (Rated) A 0.17
Power Consumption (Rated) W 53
Air Direction Control UP, DOWN, LEFT, RIGHT
Air Filter CATECHIN
Dimensions (H X W X D) inch (mm) 11-1/3 X 30-29/32 X 9-27/32 (288 X 785 X 250)
Packaged Dimensions (H X W X D) inch (mm) 13-7/8 X 32-3/4 X 12-3/8 (350 X 830 X 314)
Weight lbs (kg) 22 (10)
Gross Weight lbs (kg) 27 (12)
Condensate Drain Size in. (mm) 3/4 (19.00)
OUTDOOR UNIT RX12A
Casing Colour IVORY WHITE
Airflow Rate High CFM 1051 966
Sound Pressure Level dBA 49
Fan
Type PROPELLER
Drive DIRECT
Fan Motor
Type DIRECT CURRENT
Index of protection (IP) 24
Insulation Grade E
Running Current (Rated) A 0.47
Power Consumption (Rated) W 43 36
Motor Output W 41
Poles 8
Compressor
Type HERMETIC SWING
Model M5SLY10/15FR-1
Oil type DAPHNE FVC50K
Oil amount oz (cm
3
) 12.4 (375)
Running Current (Rated) A 3.35 4.06
Power Consumption (Rated) W 776 949
Heat Exchanger Type FIN TUBE
Starting Current A 6.06
Dimensions (H X W X D) inch (mm) 21-11/16 X 26-1/2 X 11-3/16 (550 X 675 X 284)
Packaged Dimensions (H X W X D) inch (mm) 24-1/64 X 31-3/8 X 15-1/8 (610 X 801 X 384)
Weight lbs (kg) 64 (29)
Gross Weight lbs (kg) 71 (32)
Drawing No. 3D128372 3D128372
Document No. (Set) 3D128372 3D128372
COOLING HEATING
INDOOR: 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB) INDOOR: 70°FDB (21.1°CDB)
OUTDOOR: 95°FDB (35°CDB) OUTDOOR: 47°FDB (8.3°CDB) / 43°FWB (6.1°CWB)
