Read Before Operation Read Before Operation
Open the front panel
Outdoor Unit
Air  lter
Outdoor temperature
sensor (back)
14
Refrigerant pipes and
inter-unit wire
Drain hose
Air outlet
Air inlet
(back and side)
Earth terminal (inside)
For 46 class
For 20/25/35 class
Refrigerant pipes and
inter-unit wire
Earth terminal (inside)
Drain hose
Air outlet
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Titanium apatite
deodorizing  lter
