Daikin FUD40B - FWC FD Series Dimensions

Outlines & Dimensions
139
Model: FWC02/03/04/05/06/08/10FD
LEFT PIPING
RIGHT PIPING
KE
KD
31
32118348
552
140
KC
KB
247
KA
32
19
552
129
183
11
7187
143
125
317
333
20
186
31
KE
KD
31
140
247
KC
KB
KA
20
552
129
183
31
186
125
317
333
19
143
87
129
71
32
31
552
321183
48
31
Dimension
Model
KA KB KC KD KE
FWC02/03FD 619 477 437 440 501
FWC04/05FD 870 726 687 690 751
FWC06FD 1060 916 877 880 941
FWC08FD 1390 1246 1207 1210 1271
FWC10FD 1600 1456 1417 1420 1481
Note: Dimension in mm
