Engineering & Physical Data
Engineering Data - Chilled Water Fan Coil Unit
MODEL FWK06EH FWK08EH FWK09EH FWK11EH FWK13EH
NOMINAL COOLING CAPACITY
Btu/h 16400 18500 24600 29600 31300
W 4800 5430 7210 8670 9160
NOMINAL SENSIBLE COOLING CAPACITY
Btu/h 14487 16108 19922 23991 25790
W 4250 4720 5840 7030 7560
NOMINAL HEATING CAPACITY
(ENTERING WATER TEMP. = 70°C)
Btu/h 30300 33400 40500 51100 54900
W 8870 9800 11880 14990 16100
NOMINAL TOTAL INPUT POWER W 95 126 167 186 227
NOMINAL RUNNING CURRENT A 0.44 0.55 0.74 0.85 1.03
POWER SOURCE V/Ph/Hz 220-240/1/50
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION LCD WIRELESS MICRO-COMPUTER REMOTE CONTROL
AIR FLOW
HIGH CFM 750 860 890 1000 1140
MEDIUM CFM 620 700 720 840 1000
LOW CFM 480 540 570 680 840
QUIET CFM 320 380 420 540 700
NOMINAL WATER FLOW RATE (COOLING)
USGPM 3.65 4.14 5.46 6.56 6.96
litres/min 13.83 15.67 20.67 24.83 26.33
NOMINAL WATER FLOW RATE (HEATING)
USGPM 3.35 3.70 4.49 5.68 6.12
litres/min 12.67 14.00 17.00 21.50 23.17
HEAD LOSS (COOLING) kPa 25 31 27 31 35
HEAD LOSS (HEATING) : 70°C kPa 30 37 38 45 51
MAX. WORKING PRESSURE kPa 1608
SURFACE AIR VELOCITY m/s 0.92 1.05 1.13 1.02 1.17
SOUND PRESSURE LEVEL (H/M/L/Q) dBA 42 / 38 /32 / 23 46 / 42 / 35 / 27 48 / 43 / 38 / 30 50 / 47 / 43 / 33 52 / 49 / 45 / 39
UNIT DIMENSION - (WITH PANEL) H X W X D mm 265 x 820 x 820 (340 x 990 x 990) 300 x 820 x 820 (385 x 990 x 990)
PACKING DIMENSION - (PANEL) H X W X D mm 341 x 916 x 916 (125 x 1020 x 1020) 376 x 916 x 916 (125 x 1020 x 1020)
UNIT WEIGHT (UNIT + PANEL) kg 26 + 4 26 + 4 28 + 4 32 + 4 32 + 4
CONDENSATE DRAIN SIZE mm 19.05
PIPE CONNECTION mm 19.05 BSP FEMALE THREAD ADAPTOR
FAN
TYPE TURBO FAN
DRIVE DIRECT
FAN SPEED
HIGH RPM 530 600 660 710 800
MEDIUM RPM 450 500 550 610 710
LOW RPM 360 400 450 510 610
FAN EFFICIENCY
HIGH % 57.10 60.50 65.00 58.30 55.70
MEDIUM % 60.50 62.10 63.00 57.20 65.40
LOW %
58.20 63.30 52.70 58.40 61.60
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR (INDUCTION)
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE B
RATED INPUT
POWER
HIGH W 95 126 167 186 227
MEDIUM W 79 103 109 151 176
LOW W 67 89 86 118 144
RATED RUNNING
CURRENT
HIGH A 0.44 0.55 0.74 0.85 1.03
MEDIUM A 0.40 0.45 0.49 0.71 0.82
LOW A 0.36 0.39 0.39 0.57 0.69
STARTING CURRENT A 0.44 0.71 0.89 1.02 1.28
MOTOR OUTPUT W 30 45 65 80 110
MOTOR
EFFICIENCY
HIGH %
35.20 37.70 30.80 40.30 48.50
MEDIUM % 25.60 25.20 24.10 31.00 40.60
LOW % 15.60 14.60 21.50 23.20 30.90
POLES 8 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.39 0.39 0.37 0.46 0.46
ROW 2 2 3 3 3
WATER VOLUME litre 1.36 1.34 1.97 2.35 2.35
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WHITE
MODE COOLING HEATING
ENTERING AIR TEMPERATURE 27°C DB / 19°C WB 20°C DB
ENTERING WATER TEMPERATURE 7°C
50°C (2 Pipes System)
70°C (4 Pipes System)
LEAVING WATER TEMPERATURE 12°C 60°C (4 Pipes System)
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
