www.DaikinApplied.com 21 IM 1267-7 • PRECISELINE AIR HANDLER

Figure 40: Horizontal Units Sizes 006 - 020 DX Coil Drill
Area
Table 6: Horizontal Units Sizes 006-020 DX Coil Drill Area
Dimensions
 006 008 010 012 016 018 020
A 7.13 7.80 7.62 7.53
Figure 41: Horizontal Units Sizes 006 - 020 DX Coil with
Reheat or Preheat Drill Area
Table 7: Horizontal Units Sizes 006-020 DX Coil with
Reheat or Preheat Drill Area Dimensions
 006 008 010 012 016 018 020
A 4.38 5.05 4.87 4.78
Figure 42: Horizontal Units Size 030 - 050 – DX Only and
DX with Preheat Drill Area
Figure 43: Sizes 030 - 050 Drill Area – DX with Reheat
