SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE121021_C
214 Operation Manual
Operation manual
1
BRC1D528
Remote controller
4PW23717-1
WARNING
Contents
page
1. Features and functions
BRC1D528 Remote controller Operation manual
THANK YOU FOR PURCHASING THIS
CONTROLLER. READ THE MANUAL
ATTENTIVELY BEFORE USING THE
INSTALLATION. AFTER READING THE
MANUAL, STORE IT IN A SAFE PLACE
FOR FUTURE USE.
Before initial operation, contact your dealer
to obtain all details concerning your air
conditioning installation.
The BRC1D528 is a state of the art remote controller
that offers full control over your installation.
- Never let the remote controller get wet, this may
cause an electric shock or fire.
- Never press the buttons of the remote controller
with a hard, pointed object. The remote controller
may be damaged.
- Never inspect or service the remote controller
yourself, ask a qualified service person to do this.
1. Features and functions..........................................1
2. Name and function of switches and icons............. 2
3. Setting up the controller.........................................4
4. Description of the operation modes.......................5
5. Operation...............................................................5
6. Programming the schedule timer.........................10
1 BASIC REMOTE CONTROLLER
The basic remote controller functions are:
• ON/OFF,
• operation mode change-over,
• temperature adjustment,
• air volume adjustment
• air flow direction adjustment.
2 CLOCK FUNCTION
The clock functions are:
• 24 hours real time clock,
• day of the week indicator.
3 SCHEDULE TIMER FUNCTION
The schedule timer functions are:
• a maximum of 5 actions can be programmed
for each day of the week (totalling 35 actions),
• schedule timer can be enabled/disabled at any
time,
• linked to a set temperature or a LIMIT
operation or an OFF operation,
• "last command" overrules previous command
until next scheduled command.
4 LIMIT OPERATION
Limit operation provides thermostat control within the
range of the set minimum and maximum temperature.
The minimum temperature setting will trigger heating,
the maximum temperature setting will trigger cooling.
