Daikin Super Multi NX FFQ25B8V1B

Outdoor Unit - 50~75 Class SiBE121021_C
392 Removal Procedure
3
Lift up and remove the
partition plate.

When reassembling, make
sure to fit the lower hook of
the partition plate.
3. Remove the sound
blanket.

Since the piping ports on the
sound blanket are torn
easily, remove the blanket
carefully.
1
Remove the sound
blanket (top upper).
2
Remove the sound
blanket (top inner).
Step
Procedure Points
Sound blanket (top upper)
(R5579)
(R5582)
Sound blanket (top inner)
