Daikin Super Multi NX FFQ60B8V1B

Outdoor Unit - 50~75 Class SiBE121021_C
372 Removal Procedure
3
Remove the 6 screws
of the front panel.
4
Remove the 1 screw of
the shield plate.
5
Slide the shield plate to
the left to release the
hooks and remove the
shield plate.
6
Release the upper 2
hooks.

Align the position of hole of
the upper hook to pull the
front panel out.
Step
Procedure Points
Front panel
(R12900)
Shield plate
(R11204)
