4-1
USM 12044 - MOOMONITOR + v4.0
Copyright Dairymaster 2016
Figure 8 - Typical View of the MooMonitor installed on the cow.
(The Weight should be centred on the cow’s neck to ensure the MooMonitor stays in position)
Figure 7 - Typical view of MooMonitor + installed on a cow
(Allow a minimum of a 100mm lap at this point)
Minimum of 100mm
lap in the strap
Weight Centred
on cow’s neck
