Dali ALTECO C-1 User Manual

38
ALTECO C-1
Frequency Range [+/- 3] dB [Hz] 74 - 26,000
Sensitivity [2.83V/1m] [dB] 83.0
Nominal Impedance [ohms] 6
Maximum SPL [dB] 103
Recommended Amplifier Power
[Watt]
40 -100
Crossover Frequency [Hz] 2,100
Crossover Principle 2-way
High Frequency Driver 1 x 21 mm
soft dome
Low Frequency/midrange Driver(s) 1 x 4½”
Enclosure Type Closed
Bass Reflex Tuning Frequency [Hz] N/A
Connection Input(s) Single
Wire/Spring
loaded push-
button
Recommended Placement On speaker/Wall
Recommended Distance from rear
wall to speaker’s rear panel [cm]
1 - 50
Dimensions (H x W x D) [mm] 190 x 160 x 255
Dimensions (H x W x D) [inches] 7.5 x 6.3 x 10.0
Weight [kg/lb] 2.8 / 6.2
Accessories Rubber feet,
manual
tABLe 2 - ALteco c-1 tecHNIcAL SPecIFIcAtIoNS
All technical specifications are subject to change without notice.

Dali ALTECO C-1 Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Tweeter	Yes
Speaker type	2-way
Tweeter diameter	21 mm
Number of drivers	2
Speaker enclosure	Closed
Speaker placement	Wall-mountable
Audio output channels	2.0 channels
Number of tweeter drivers	1
Impedance	6 Ω
Sensitivity	83 dB
Frequency range	74 - 25000 Hz
RMS rated power	- W
Crossover frequency	2100 Hz
Signal-to-Noise Ratio (SNR)	103 dB
Recommended amplifier power (max)	100 W
Recommended amplifier power (min)	40 W
Connectivity technology	Wired

Weight and Dimensions

Depth	200 mm
Width	160 mm
Height	265 mm
Weight	2900 g
