Dali speakers - Amplifier with separate preamplifier output terminal and detachable power amplifier; Amplifier without separate preamplifier output terminal and detachable power amplifier

Amplier with separate preamplier
output terminal and detachable power
amplier (Fig. 6)
Piano Forte is operated by a signal from
your preamplier/surround decoder.
Piano Forte operates the front speakers
via the built-in active crossover network
and a separate power amplier.
Amplier without separate preamplier
output terminal and detachable power
amplier (Fig. 7)
With this solution you have the option of
using a more powerful power amplier for
the front speakers. The partially passive
solution means that Piano Forte is operated
by the speaker signal from your amplier
and converts this signal into a line signal
that operates both the subwoofer and the
power amplier for the front speakers.
Piano Forte should be positioned with the speaker unit facing the wall.
7
English
Fig. 6
Fig. 7
