DALMEC ANTARTIDE ECC700TN - Page 18

18
Front view
1 - compressor neutral
2 - fan neutral
3 - defrost neutral
4 - compressor phase
5 - fan phase
6 - defrost phase
1
2
3
4
5 6
ResistorCondenser fanB
CompressorA Evaporator fan
D
C
M1
C
M1
BA
D






Electric scheme ST36, ST52, ST54
