Dametric TVD-M2 / TVD-M3
TVD-M2-M3 EN.docx May 26, 2011 / BL 6(8)
4.4 Low gain filter response
4.4.1 With 10 kHz transducer type setting
a 0.3 kHz b 2 kHz c 4 kHz d 6 kHz e 8 kHz f 19 kHz
4.4.2 With 40 kHz transducer type setting
a 0.3 kHz b 2 kHz c 4 kHz d 6 kHz e 8 kHz f 19 kHz
1k 10k 40k frequency
gain
0.2
0.4
0.6
0.8
1
100
a
b
c
d
e
f
1k 10k 40k frequency
gain
0.2
0.4
0.6
0.8
1
100
a
b
c
d
e
f
