5
Step 4
Push the beams onto
the remaining leg frame
lining up the beam holes
with the M6 threaded
holes on the leg.
Please Note
If you have purchased a
larger configuration of
desk than the one
shown please refer to
the FZ1600IL instruction
before proceeding with
step 4
4
5
Step 5
Once the holes are
aligned fix the beam in
place using the
M6 x 25mm Connect
Bolts.
8x
M6 x 25mm Connect Bolt
Please Note
If you have purchased a sliding top system please refer to the sliding top
bracket assembly instruction from this point onwards.
