dams FZ1600OL - Page 8

8
8
8x
M6 x 60mm Connect Bolt
Step 8
Attach one side of the
desktops to the frame
using the M6 x 60mm
Connect Bolts.
Ensure that the bolt
passes through both
the leg frame and
Spacer Block.
9
8x
M6 x 60mm Connect Bolt
Step 9
Attach the remaining
side of the desktops to
the frame using the M6
x 60mm Connect Bolts.
Ensure that the bolt
passes through both
the leg frame and
Spacer Block.
