6
External Water Tank Instructions (cont'd)
3.
Position the external water tank on the
support tray, making sure the quick connect
on the water tank is aligned with the factory
installed quick connect at the back of the
cabinet. See Fig.37
4. To make the connection, simply "push" the
water tank quick connect into the cabinet
quick connect. You will hear a positive
"click" when the connection is made.
5. Install the cover on the water tank.
6. To release (disconnect) the external water
tank, simply push down the (silver) "release"
button located on top of the cabinet quick
connect, grasp the recessed handles on
each side of the tank, lift and pull the tank
towards you.
See fig.38, 39
Fig.38
Fig.37
Fig.39
CAUTION
Before attempting to move or re-locate the unit,
accumulated water in both tanks should be emptied.
