Danfoss OP-MPHM007NFP00G User Manual

3FRCC.ES.010.A4.ML
Manual Controller Installation
Code (controller
parameter o61 )*
Model* Optyma Plus
TM
New
Generation
Code-no. Compressor* Refrigerant (controller parameter o30)*
settings are adjustable*
R404A
(19)
R507
(17)
R134a
(3)
R407C
(20)
R22
(2)
R407A**
(21)
R407F**
(37)
1 OP-MPHM007NFP00G 114X4101 NF7MLX X x
2 OP-MPHM010SCP00G 114X4102 SC10MLX X x
3 OP-MPHM012SCP00G 114X4104 SC12MLX X x
4 OP-MPHM015SCP00G 114X4105 SC15MLX X x
5 OP-MPHM018SCP00G 114X4109 SC18MLX X x
6 OP-MPGM034GSP00G 114X4210 GS34MFX x
7 OP-MPHM026GSP00G 114X4214 GS26MLX X x
8 OP-MPHM034GSP00G 114X4229 GS34MLX X x
9 OP-MPZM030MTP00E - MTZ22-4VM X x x x x x
10 OP-MPZM048MTP00G - MTZ28-5VM X x x x x x
11 OP-MPZM048MTP00E - MTZ28-4VM X x x x x x
12 OP-MPZM060MTP00G - MTZ36-5VM X x x x x x
13 OP-MPZM060MTP00E - MTZ36-4VM X x x x x x
14 OP-MPZM086MTP00E - MTZ51-4VM X x x x x x
15 OP-MPZM086MTP00H - MTZ50-6VM X x x x x x
16 OP-MPZM108MTP00E - MTZ65-4VM X x x x x x
17 OP-MPZM108MTP00H - MTZ64-6VM X x x x x x
18 OP-MPZM136MTP00E - MTZ81-4VM X x x x x x
19 OP-MPZM136MTP00H - MTZ80-6VM X x x x x x
20 OP-LPHM018SCP00G 114X3109 SC18CLX.2 X x
21 OP-LPHM026GSP00G 114X3217 GS26CLX X x
22 OP-LPHM048NTP00G 114X3225 NTZ48-5VM X x
23 OP-LPHM048NTP00E 114X3233 NTZ48-4VM X x
24 OP-LPHM068NTP00G 114X3241 NTZ68-5VM X x
25 OP-LPHM068NTP00E 114X3249 NTZ68-4VM X x
26 OP-LPHM096NTP00E 114X3357 NTZ96-4VM X x
27 OP-LPHM136NTP00E 114X3365 NTZ136-4VM X x
28 OP-MPUM034MLP00G 114X4261 MLZ015T5LP9 X x x x x x
29 OP-MPUM034MLP00E 114X4264 MLZ015T4LP9 X x x x x x
30 OP-MPUM046MLP00G 114X4281 MLZ021T5LP9 X x x x x x
31 OP-MPUM046MLP00E 114X4284 MLZ021T4LP9 X x x x x x
32 OP-MPUM068MLP00G 114X4308 MLZ030T5LC9 X x x x x x
33 OP-MPUM068MLP00E 114X4311 MLZ030T4LC9 X x x x x x
34 OP-MPUM080MLP00G 114X4321 MLZ038T5LC9 X x x x x x
35 OP-MPUM080MLP00E 114X4324 MLZ038T4LC9 X x x x x x
36 OP-MPUM108MLP00E 114X4344 MLZ048T4LC9 X x x x x x
37 OP-MPUM125MLP00E 114X4414 MLZ058T4LC9 X x x x x x
38 OP-MPUM162MLP00E 114X4434 MLZ076T4LC9 X x x x x x
39 OP-LPHM215LLP00E 114X3476 LLZ024T4LC9 X x
40 OP-LPHM271LLP00E 114X3482 LLZ033T4LC9 X x
41 OP-MPUM057MTP00G 114X4290 MLZ026T5LP9 X x x x x x
42 OP-MPUM057MTP00E 114X4293 MLZ026T4LP9 X x x x x x
43 OP-LPHM067LLP00E - LLZ013T4LC9 X x
44 OP-LPHM084LLP00E - LLZ015T4LC9 X x
45 OP-LPHM098LLP00E - LLZ018T4LC9 X x
46 OP-MPHM024AJP00G 114X4200 CAJ9513Z X
47 OP-MPHM026AJP00G 114X4212 CAJ4517Z X
48
OP-MPHM026AJP00E 114X4213 TAJ4517Z X
49 OP-MPHM034AJP00G 114X4226 CAJ4519Z X
50 OP-MPHM034AJP00E 114X4227 TAJ4519Z X
51 OP-LPHM026AJP00G 114X3216 CAJ2446Z X
52 OP-MPGM033AJP00G 114X4220 CAJ4511Y x
53 OP-LPHM074FHP00G 114X3252 FH2511Z X
54 OP-LPHM074FHP00E 114X3253 TFH2511Z X
Code (controller parameter o61 ): Code (contrôleur paramètre o61 / Code (Reglerparameter o61) / Kode (regulatorparameter o61)
Model
: Modèle / Modell / Model
Code-no. : Code n° / Art-Nr. / Bestillingsnr.
Compressor
: Compresseur / Verdichter / Kompressor
Refrigerant : Réfrigérant (contrôleur paramètre o30) / Kältemittel (Reglerparameter o30) / Kølemiddel (regulatorparameter o30)
*Settings are adjustable : parameters sont réglables / Werte einstellbar / indstillinger er justerbare
**Ongoing qualications for condensing units
Optyma Plus™ condensing units are pre-parameterized, depending on the model of compressor
mounted and the type of refrigerant. In the case of a “multi-refrigerant” compressor (e.g. MTZ or MLZ),
the controller parameter “o30” for refrigerant is set to R404A and must be changed for other refrigerants
(see chapter Commissioning - Quick start of the unit / Refrigerant change).
Annex
