Danfoss VLT 5016 User Manual

Compact, AC line supply 3 x 380-500 V
According to international requirements VLT type 5122 5152 5202 5252 5302
Normal overload current (110%):
Output current
I
VLT,N
[A] (380-440 V)
212 260 315 395 480
I
VLT, MAX
(60 s) [A] (380-440
V)
233 286 347 434 528
I
VLT,N
[A] (441-500 V)
190 240 302 361 443
I
VLT, MAX
(60 s) [A] (441-500
V)
209 264 332 397 487
Output
S
VLT,N
[kVA] (400 V)
147 180 218 274 333
S
VLT,N
[kVA] (460 V)
151 191 241 288 353
S
VLT,N
[kVA] (500 V)
165 208 262 313 384
Typical shaft output
[kW] (400 V)
110 132 160 200 250
[HP] (460 V) 150 200 250 300 350
[kW] (500 V) 132 160 200 250 315
High overload torque (160 %):
Output current
I
VLT,N
[A] (380-440 V)
177 212 260 315 395
I
VLT, MAX
(60 s) [A] (380-440
V)
266 318 390 473 593
I
VLT,N
[A] (441-500 V)
160 190 240 302 361
I
VLT, MAX
(60 s) [A] (441-500
V)
240 285 360 453 542
Output
S
VLT,N
[kVA] (400 V)
123 147 180 218 274
S
VLT,N
[kVA] (460 V)
127 151 191 241 288
S
VLT,N
[kVA] (500 V)
139 165 208 262 313
Typical shaft output
[kW] (400 V)
90 110 132 160 200
[HP] (460 V) 125 150 200 250 300
[kW] (500 V) 110 132 160 200 250
Max. cable cross-section to
motor
[mm
2
]
4,6
[AWG]
2,4,6
2 x 70
2 x 2/0
2 x 185
2 x 350 mcm
Max. cable cross-section to
load sharing and brake
[mm
2
]
4,6
[AWG]
2,4,6
2 x 70
2 x 2/0
2 x 185
2 x 350 mcm
Normal overload current (110%):
Rated input current
I
L,N
[A] (380-440 V)
208 256 317 385 467
I
L,N
[A] (441-500 V)
185 236 304 356 431
High overload torque (160 %):
Rated input current
I
L,N
[A] (380-440 V)
174 206 256 318 389
I
L,N
[A] (441-500 V)
158 185 236 304 356
Max. cable cross-section
power supply
[mm
2
]
4,6
[AWG]
2,4,6
2 x 70
2 x 2/0
2 x 185
2 x 350 mcm
Max. pre-fuses (line) [-]/UL
[A]
1
300/
300
350/
350
450/
400
500/
500
630/
600
Efficiency
3
0,98
Power loss
Normal overload [W]
2619 3309 4163 4977 6107
High overload [W] 2206 2619 3309 4163 4977
Weight
IP 00 [kg]
82 91 112 123 138
Weight
IP 21/NEMA 1 [kg]
96 104 125 136 151
Weight
IP 54/NEMA 12 [kg] 96 104 125 136 151
Enclosure IP 00, IP 21/NEMA 1 and IP 54/NEMA 12
1. For type of fuse, see section Fuses.
2. American Wire Gauge.
3. Measured using 100 ft [30 m] shielded motor cables at rated load and rated frequency.
4. Max. cable cross-section is the maximum possible cable cross-section allowed to be fitted on the terminals. Always comply with
national and local regulations on min. cable cross-section.
5. Weight without shipping container.
6. Connection bolt power supply and motor: M10; Brake and load sharing: M8
VLT
®
5000 Series
MG.51.C5.22 - VLT
p
is a registered Danfoss trademark. 21
Technical data
