Block

Diagram

Name

Spare

Part

Number

Spare Part Name Comments 200–240 V AC

D1h/D3h D2h/D4h

FC 102 (T2) N55K N75K N90K N100 N150 N160

FC 202 (T2) N55K N75K N90K N100 N150 N160

FC 302 (T2) N45K N55K N75K N90K N100 N150

CBL4 176F3322 Cable power crd to CT D1h-D3h wire harness-power crd to current sensors & mixing fan 1 1 1 – – –

CBL4 176F3323 Cable power crd to CT D2h/D4h wire harness-power crd to current sensors & mixing fan – – – 1 1 1

CBL5 176F3324 Cable DC bus to power crd D1h/D3h wire harness-power crd to DC Bus 1 1 1 – – –

CBL5 176F3325 Cable DC bus to power crd D2h/D4h wire harness-power crd to DC Bus 1 1 1 1 1 1

CBL6 176F3326 Cable power crd to HF/RFI D1h/D3h wire harness-power crd to RFI 1 1 1 – – –

CBL6 176F3327 Cable power crd to HF/RFI D2h/D4h wire harness-power crd to RFI – – – 1 1 1

CBL7 176F3328 Cable power crd to gate drive D1h/D3h ribbon cable-power crd to gate drive bd 1 1 1 – – –

CBL7 176F3329 Cable power crd to gate drive D2h/D4h ribbon cable-power crd to gate drive bd – – – 1 1 1

CBL8 176F3331 Cable gate drive to Inrush D1h/D3h ribbon cable-inrush crd to gate drive bd 1 1 1 – – –

CBL8 176F3332 Cable gate drive to Inrush D2h/D4h ribbon cable-inrush crd to gate drive bd – – – 1 1 1

CBL10 176F3333 Cable Inrush to SCR gate D1h/D3h wire harness-inrush crd to SCR gates 1 1 1 – – –

CBL10 176F3336 Cable Inrush to SCR gate D2h/D4h wire harness-inrush crd to SCR gates – – – 1 1 1

CBL11 176F3179 Cable brake IGBT gate signal D1h D3h wire harness-gatedrive bd to brake IGBT gate, 1 per kit 1 1 1 – – –

CBL11 176F3180 Cable brake IGBT gate signal D2h D4h wire harness-gatedrive bd to brake IGBT gate, 1 per kit – – – 1 1 1

CBL12 176F3177 Cable IGBT temp to gate PCA D1h D3h wire harness-gatedrive bd to IGBT NTC, 1 per kit 1 1 1 – – –

CBL12 176F3178 Cable IGBT temp to gate PCA D2h D4h wire harness-gatedrive bd to IGBT NTC, 1 per kit – – – 1 1 1

CBL13 176F3175 Cable IGBT gate signal D1h D3h wire harness-gatedrive bd to IGBT gate, 1 per kit 3 3 3 – – –

CBL13 176F3176 Cable IGBT gate signal D2h D4h wire harness-gatedrive bd to IGBT gate, 1 per kit – – – 3 3 3

Busbars

176F3338 Busbar SCR AC input D1h/D3h busbars 3 3 3 – – –

176F3339 Busbar DC+ inductor to cap bank D1h/D3h busbars 1 1 1 – – –

176F3340 Busbar DC- inductor to cap bank D1h/D3h busbars 1 1 1 – – –

176F3341 Busbar IGBT AC output D1h/D3h busbars 3 3 3 – – –

176F3346 Busbar assembly SCR to DC coil D1h/D3h busbars 1 1 1 – – –

176F3347 Busbar assembly Current sensor D1h/D3h busbars 1 1 1 – – –

176F6517

Busbar assembly LEM 310A curr sensor

D1h/D3h busbars 1 1 1 – – –

176F3350 Busbar assembly cap bank 400V D1h/D3h busbars 1 1 1 – – –

176F3356 Busbar motor terminals U,V,W D1h/D3h busbars 1 1 1 – – –

176F3357 Busbar mains, no fuse, no RFI D1h/D3h busbars 1 1 1 – – –

176F3358 Busbar mains, fuse, no RFI D1h/D3h busbars 1 1 1 – – –

176F3359 Busbar mains, RFI, no fuse D1h/D3h busbars 1 1 1 – – –

Spare Parts Service Guide

15 15
